Automatic Electronic Compression Testing Machine Table Type Tensile Strength Tester
1. Quick Details
| Alternative name | Table type tensile strength tester With Serve Motor |
| Function | Test for tensile strength, elongation, extension, and peeling, tearing strength of leather, fabrics, shoes... |
| Type | Table type electronic tensile tester |
| Weight | 70kg |
| Volume | 80×53×180cm(W×D×H) |
| Corresponding test standard | ASTM D1790,D1593,JIS K6545,HB-T2877, CNS-7705 |
2. Description
Tensile testing equipment is widely used in controlling the quality; Rubber, Plastics;
metallurgical iron and steel; manufacturing machinery; electronic equipment; automobile production;
textile fiber; wire and cable; packaging materials...
Test including: tensile strength, elongation, extension rate, peeling, tearing, bending resistance, flexing,
compression, shearing and adhesive strength.
3. Features
a. Elegant and nice structure design
b. Precise leading screw
c. Advanced controlling system- data sampling and drive control by computer
d. Powerful software function- fully opening testing software. Users can finished all mechanics test
items by this existing software, but also can edit exclusive test method according to specifical
requirement.
e. Excellent test accuracy - better 1 degree, 1/100,000 strength resolution; resolution of deformation
measurement is 0.001mm.
4. Specifications
| Model | GX-8004 |
| Load range | 5-200kg |
| Unit exchange | kgf,gf,Ton,lbf,N,kN |
| Accuracy of load | ± 0.5% of indicated value |
| Load resolution | 1/10,000 |
| Deformation measuring resolution | 0.01mm |
| Action | Tensile and compression function |
| Load Magnifying Rate | Variable speed |
| Max. tensile space | 650 mm (not including fixture) |
| Valid test width | 400mm |
| Test speed range | 25～500mm/min |
| Input mode of speed | Button |
| Speed accuracy | ± 0.5% |
| Displacement accuracy | 0.001mm |
| Data sampling | 50 r/s |
| Spacing function | 10 spacings for each time, the smallest and largest data will display and average value will be calculated automatically |
| Display | LCD |
| Motor | AC motor |
| Control system | Electronic |
| Weight | 70kg |
| Standard Accessories | 1 Sensor; A pair of tensile fixture; a pair of universal functional fixture; |
| Power | AC220V,50/60Hz,15A |
5.Company information
Dongguan Gaoxin Testing Equipment Co., Ltd is a high tech company specialized in producing kinds of testing equipment which was established in 2007, located in manufacturing centre of China-Dongguan City where is close to Guangzhou city and Hong Kong.
Our advantages:
(1) Speciality in testing equipment
(2) Various products to choose from
(3) Accept customization
(4) Excellent after-sale service
